Two variable frequencies controls are installed on the Front panel.
ARS MODEL-3500 is an innovative frequency isolator with adjustable crossover frequency control.
Users can adjust the crossover point to choose which frequency ranges of “LOW”, “MID” and “HIGH” should be emphasized for their preferences and music genres.
Maximum Boost 18dB provides the users to be well aware of changes and is good for protection of speaker systems. Volume curve is designed with insistence on quick attack and sharp response.
Its simplified design minimizing all possible sound degradation.
ARS MODEL-3500 provides superior controls for DJs to react to each different scenarios, giving more characteristics to their performance.
* HI/MID/LOW frequencies are completely separated giving each independent level controls.
Each band frequencies can be controlled the range of +18db to -infinity.
* Two variable frequencies controls are installed on the Front panel.
One is for adjusting the LOW/MID crossover point, the other is for the MID/HI crossover point.
Due to the feature of being able to set the midrange frequencies narrow or widen, the MODEL 3500 can be functional any musical genres.
* For the input sources, either RCA unbalanced jacks or XLR balanced jacks (2HOT) can be connected.
* For the output sources, both RCA unbalanced jacks and XLR balanced jacks can be connected simultaneously since both jacks has independent output circuits.
* Knobs have brims on the center point to easily identified the center with a little light in the clubs.
* 100 mm width intervals between knobs give smooth operation to improve DJ performance
* No power switch avoiding accidentally turning power off while playing.
* Minimizing the power noise by designing the main circuit board and the power circuit board independently and setting them apart.
[SPEC]
Frequency Response: +-1dB 20Hz-20Khz (with no EQ)
Input: RCA Unbalanced Impedance 20k Ohm / XLR Balanced Impedance 40ｋOhm
Output:RCA Unbalanced Impedance 600 Ohm / XLR Balanced Impedance 50 Ohm
Maximum Output Level:+20 dB
Crossover Type: Low Mid Hi 3 Band 18dB Octave / Crosspoint: Variable Low Mid: 50Hz-500Hz / Mid Hi: 1Khz-10Khz
Crossover/Bypass Switch: Selector switch on the right of the front panel (*Silver front panel color type doesn't have this feature)
Power Requirement: US-115V/EU-230V(Selectable)
Power Consumption: 10w
Dimensions: Front Panel 1U (W)482 x (H)44 x (D)195 mm
Front Panel Color: Black
Spec Seat: Manufacturer site
HI/MID/LOW frequencies are completely separated giving each independent level controls. Each band frequencies can be controlled the range of +18db to -infinity.
