ARS MODEL 6700 MUSIC MIXER　Final manufactured product [ARS MODEL 6700]

MODEL6700 Music Mixer


ARS MODEL 6700 DJ Mixer is a Japanese made,All hand crafted DJ mixer.
6 ch. rotatry mixer with isolator on each chanell.
The ARS 6700 is our flagship model.
This 6 channel High Quality Rotary DJ Mixer has a 3 band isolator across each channel and and a 5 band eq on the master which is equal to the Model 5000.
A long time in the development phase this mixer is a beautiful example of Japanese hand made precision workmanship.
Highly recommended.


It is designed with purist ideals with only essential features.
It is based the ARS 4100 but has 3 band isolators on each channell and 5 band EQ on its master.
The isolators can be boost of cut from +18db ~ -∞.
The 5Band eq can boost or cut from +12db ~ -12db.
Each channell has Send. also Return and Effect Loop.
House and Booth have the same PCBs so the output sound should be exactly the same.

* No power switch avoiding accidentally turning power off while playing.
* Minimizing the power noise by designing the main circuit board and the power circuit board independently and setting them apart.


[SPEC]
Frequency Response: +-1dB 20Hz-20Khz
Input: 3 x Phono: 47K Ohm / 9 x Line: 20K Ohm
House Output:RCA Unbalanced Impedance 600 Ohm/ XLR Balanced Impedance 50 Ohm
Booth Output:RCA Unbalanced Impedance 600 Ohm/ XLR Balanced Impedance 50 Ohm
Tape Output: RCA Unbalanced Impedance 600 Ohm
Effect Loop: RCA Unbalanced Impedance 20K Ohm
Effect Loop Output:RCA Unbalanced Impedance 600 Ohm
Send Output: RCA Unbalanced Impedance 600 Ohm
Retrun: RCA Unbalanced Impedance 20K Ohm
Isolator Frequency Response:(Not 3Band EQ) 3Band Iso 1-6Ch /Master 10 – 300 Hz / 300 – 3000 Hz / 3000 – 20000Hz
5Band Equalizer Control: 75Hz 300Hz 1Khz 3Khz 10Khz 5Band
Power Consumption: 30w
Power Requirement: US-115V/EU-230V(Selectable)
Dimensions: Front Panel 4U (W)482.6 x (H)176 x (D)195 mm
Front Panel Color: Black
Spec Seat: Manufacturer site
