ARS MODEL 3600 with PHONO Pre Amps and LINE Model final edition [ARS MODEL 3600 PHONO]

24 dB/Octave 3-Way DUAL channel crossover with 2 Phono Pre Amps

Users can adjust the crossover point to choose which frequency ranges of "LOW", "MID" and "HIGH" should be emphasized for their preferences and music genres.
Volume curve is designed with insistence on quick attack and sharp response.
Its simplified design minimizing all possible sound degradation. ARS MODEL-3600 provides superior controls for DJs to react to each different scenarios, giving more characteristics to their performance.

Users can select PHONO / LINE inputs by selectable switches.

* No power switch avoiding accidentally turning power off while playing.
* Minimizing the power noise by designing the main circuit board and the power circuit board independently and setting them apart.

[SPEC]
Frequency response : +-1db 20hz-20khz
Input RCA: LINE impedance 20K Ohm
Output:
RCA impedance 600 Ohm
PHONO impedance: 47K Ohm x 2
Maximum Output Level: +-20 dBu
Crossover Type: 10 - 300 Hz / 300 - 3500 Hz / 3500 - 25000Hz ＋18dB〜－∞cut on each bandwidth

Front: PHONO/LINE selectable switch (Only optional pre amps are added)
Power requirement: 115VAC/230VAC 50/60Hz
Power consumption: 10w
Dimensions: Front Panel 1U (W)482 x (H)44 x (D)195 mm
Front panel color: Black
